Model 2210 Surface Mount #8 or #10 screw

• On Delay

The 2210 is designed for use as a maintenance reminder or lockout, it starts timing upon application of input power and retains count during removal of power. Input power frequency is used for an accurate time base. A six position dip switch selects the desired time delay. Switch settings can only be changed when output is on. A status LED indicates unit is timing. The solid state 1 Amp output can handle a variety of loads.

Product Sheet

Specifications

Input

Voltage: 20 to 250 VAC/DC

Frequency: 50/60 Hz or DC

Output

Type: Solid State N.O. Zero Voltage Crossing

Rating: 1A @ 240VAC/DC max.

Voltage Drop::<1.6 volts at 1A

Timing

Timing Function: On Delay

Time Range: 1 minute to 10230 days in 3 ranges

Range Tolerance:<250 msec per application of power

Control: Power applied to input initiates timing cycle

Physical

Operating Temp:-25° to 70° C (-13° to 158° F)

Termination: 3-Pin mini-style connector

Wiring

Dimensions

Ordering Data
